Rich Solar 10kWh All in One Powerwall

Name: Rich Solar 10kWh All in One Powerwall
SKU: RS-A10
Price: 5899.99 USD
Availability: InStock

Write a Review

Ask a Question

Item Code: RS-A10

Ship Weight: 300 lbs.

Regular Price: $8,999.99

Spring Sale: $5,899.99

You Save 34% ($3,100.00)

Product Details

Introducing the Rich Solar All in One Powerwall. This all in one solar energy system is powerful and efficient, and is designed to provide clean and reliable electricity. This innovative system integrates all the components required for solar power generation into a single, compact unit, including an inverter, batteries, and a charge controller.

Powerful:

•	Rated Out Power of 6500 Watts for all of your power hungry 120V electronics and appliances.

Features:

•	Perfect for an off-grid application with programable supply priority for PV, Battery or Grid.
•	Features a user-adjustable battery charging current and battery independent design.
•	Has multiple communication for USB, RS232, SNMP, Modbus, GPRS and Wi-Fi and comes with an app for real-time status displays and parameter control.
•	Has 2 built-in MPPT trackers and AC/Solar charger up to 120A . The All-in-one is compatible with utility and generators and supports battery expansion.

Compact Design:

•

The compact design of an All in One Energy Storage System makes it an attractive option for those with limited space, or for those who want a more discreet installation. It can also be easier to install and maintain compared to larger energy storage systems, which may require more extensive wiring and infrastructure.

Battery:

•

The All in One Energy Storage System also features a high-capacity battery bank, which allows you to store excess energy generated by the solar panels for use during times when sunlight is not available. This means that can continue to power your home or business with clean, renewable energy even when the sun is not shining.

Inverter:

•	The system's advanced inverter technology ensures that the electricity generated by the solar panels is converted into a form that is compatible with your home or business's electrical system, allowing you to power your appliances and devices without interruption.

Controller:

•	The system's intelligent charge controller ensures that the battery bank is charged and discharged in the most efficient way possible, prolonging the lifespan of the batteries and maximizing their overall performance.

Specifications

All in One Powerwall
Manufacturer Name:	Rich Solar
Model:	RS-A10
Maximum PV Input Power:	8000W
Rated Output Power:	6500W
Maximum Charging Power:	6500W
Waveform:	Pure sine wave
Weight:	287 lb
Dimensions:	19.7" L x 26" W x 49.2" H
Solar Charger Input
MPPT Range @ Operating Voltage:	90 - 230VDC
Maximum PV Array Open Circuit Voltage:	250VDC
Maximum Solar Charge Current:	120A
Efficiency (Peak):	93%
Number of MPP Trackers / Maximum Input Current:	2 / 2 x 18 A
AC Input
Acceptable Input Voltage Range:	90-140 VAC (For Computers) 80-140 VAC (For Home Appliances)
Maximum AC Input Current:	60A
Battery Mode Output
Nominal Output Voltage:	120 VAC
Maximum Conversion Efficiency (DC/AC):	93%
Battery
Nominal DC Voltage:	48 VDC
Maximum Charging Current:	120A
Dimensions:	8.4"x24.4"x19.7"
Weight:	99 lbs
Capacity:	5120Wh
Nominal Voltage:	51.2VDC
Full Charge Voltage(FC):	56V
Full Discharge Voltage(FD):	42V
Typical Capacity:	100 Ah
Max Continuous Discharging Current:	120A
Max Discharging Current:	192A at 1 min
Protection:	BMS, Breaker
Float Charge Voltage:	52.5V
Charge Current:	20A (0.2C)
Maximum Charge Current:	50A (0.5C)
Standard Charge Method:	0.2C CC (Constant current) charge to FC,CV (Constant voltage FC) charge till charge current decline to <0.05C
Inner Resistance::	≤20m ohm

Product Manual

What's Included

What's Included:

• (1) Rich Solar 10kWh All in One Powerwall
